Product Description
1>High Energy Efficiency
Meet IE2 efficiency standard (IE3 optional)
Optimized electromagnetic design reduces energy losses
2>Robust Construction
Heavy-duty cast iron frame
Class F insulation (155°C thermal class)
IP55 protection standard (IP56 optional)
3> Superior Performance
High starting torque (up to 250% of rated torque)
Low vibration (<2.8mm/s) and noise (<75dB)
Excellent overload capacity (150% for 2 minutes)
4>Versatile Application
Wide power range: 0.55-315kW
Multiple speed options: 2/4/6/8 pole
Various mounting configurations available
Feature Specification
Efficiency Class ：IE2 (IE3 optional)
Power Range ： 0.55-315kW
Voltage ：380V/50Hz (other voltages available)
Speed ：3000/1500/1000/750 RPM
Protection Class ： IP55 (IP56 optional)
Insulation Class ： Class F (155°C)
Cooling Method ： IC411 (IC416 optional)
Ambient Temp. ：-15°C to +40°C
Technical Table
| Type 型号 | Rated Output 功率 | Current电流 (A) | Power factor 功率因素 (cosφ) | Eff 效率 (%) | Rated Speed 转速 (r/min) | 堵转电流 额定电流 Ist/In | 堵转转矩 额定转矩 Tst/Tn | 最大转矩 额定转矩 Tmax/Tn | |
| KW | Hp | ||||||||
| YL711-2 | 0.37 | 1/2 | 2.73 | 0.92 | 67 | 2750 | 16 | 1.8 | 1.7 |
| YL712-2 | 0.55 | 3/4 | 3.88 | 0.92 | 70 | 2750 | 21 | 1.8 | |
| YL801-2 | 0.75 | 1 | 4.78 | 0.92 | 72 | 2800 | 29 | 1.8 | |
| YL802-2 | 1.1 | 1.5 | 6.93 | 0.95 | 75 | 2820 | 40 | 1.8 | |
| YL90S-2 | 1.5 | 2 | 9.44 | 0.95 | 76 | 2820 | 55 | 1.7 | |
| YL90L-2 | 2.2 | 3 | 13.7 | 0.95 | 77 | 2830 | 80 | 1.7 | |
| YL100L-2 | 3 | 4 | 18.4 | 0.95 | 79 | 2850 | 110 | 1.7 | |
| YL112M-2 | 3.7 | 5 | 22.1 | 0.95 | 80 | 2850 | 160 | 1.7 | |
| YL711-4 | 0.25 | 1/3 | 1.99 | 0.92 | 62 | 1360 | 12 | 1.8 | |
| YL712-4 | 0.37 | 1/2 | 2.81 | 0.92 | 65 | 1360 | 16 | 1.8 | |
| YL801-4 | 0.55 | 3/4 | 3.77 | 0.92 | 68 | 1400 | 21 | 1.8 | |
| YL802-4 | 0.75 | 1 | 5.08 | 0.92 | 71 | 1400 | 29 | 1.8 | |
| YL90S-4 | 1.1 | 1.5 | 7.02 | 0.95 | 73 | 1410 | 40 | 1.7 | |
| YL90L-4 | 1.5 | 2 | 9.44 | 0.95 | 75 | 1420 | 55 | 1.7 | |
| YL100L1-4 | 2.2 | 3 | 13.7 | 0.95 | 76 | 1430 | 80 | 1.7 | |
| YL100L2-4 | 3 | 4 | 18.4 | 0.95 | 77 | 1430 | 110 | 1.7 | |
| YL112M1-4 | 3 | 4 | 18.4 | 0.95 | 77 | 1430 | 110 | 1.7 | |
| YL112M2-4 | 3.7 | 5 | 22.1 | 0.95 | 80 | 1450 | 138 | 1.7 | |
| YL132S1-4 | 3.7 | 5 | 22.1 | 0.95 | 80 | 1450 | 138 | 1.7 | |
| YL132S2-4 | 5.5 | 7.5 | 32.5 | 0.95 | 81 | 1450 | 227 | 1.7 | |
FAQ
1 Q: Is AXSON a factory or a trading company?
A; AXSON is a factory.
2 Q: How long is the warranty period?
A; The warranty period for the equipment is 12 months from the Bill of Lading (B/L) date, with a 6-month warranty for spare parts (excluding wear parts).
3 Q:What is the payment terms?
A; 30% deposit by TT, with the remaining 70% payable before shipment or against copy of Bill of Lading (B/L).
4 Q: Does AXSON offer on-site support?
A; Yes, AXSON can dispatch engineers to provide on-site services, with the client bearing all associated costs for accommodation, meals, and interpreter services.
5 Q: How long is your delivery time?
A; If items are in stock, shipment will be made within 7-10 days. For made-to-order production, the lead time is 30 days.
6 Q: Can you provide a turnkey solution for the complete crushing plant?
A; We offer end-to-end solutions from design to commissioning, with full technical support. We have successfully executed multiple similar mining projects in China and overseas markets
7 Q: How to select the proper equipment model?
A: Please confirm the following details:
1.>Type of ore to be processed? (e.g. gold ore/granite/limestone)
2.>Feed size of raw material? (in millimeters)
3.>Required finished product size? (in millimeters)
4.>Production capacity requirements? (in tons per hour)
8 Q: Do you provide customized components and optional configurations?
A: We offer full customization including engines, screens, painting, etc., along with extensive optional packages.
9 Q: Why Choose Us as Your Equipment Manufacturer?
A: We don’t just deliver high-quality, cost-effective products—we also provide:
1.Customized solutions tailored to your needs
2. Professional end-to-end service
3. A more patient, detail-oriented, and responsible team
4. 24/7 support to ensure smooth operations
