Product Description
● Energy Efficient Operation
IE2 efficiency standard (upgradable to IE3)
● Compact & Space-Saving
Lightweight aluminum alloy housing
20-30% smaller footprint than comparable models
Ideal for equipment with space constraints
● Quiet & Smooth Performance
Precision-balanced rotor (noise level <65dB)
Vibration-dampening rubber mounts
Ideal for residential and office environments
● Reliable Starting Performance
Capacitor-start design provides high starting torque
Handles 150% overload for short durations
Stable operation under voltage fluctuations (±10%)
● Durable Construction
Class F insulation (155°C thermal rating)
IP54 protection against dust and water splashes
Sealed pre-lubricated bearings (maintenance-free)
Feature Specification
Power Range : 0.09-3.7kW (1/8-5HP)
Voltage : 220V/50Hz (standard), 110V/60Hz (optional)
Speed Options : 1400 RPM (4-pole), 2800 RPM (2-pole)
Mounting Types : B3 (foot), B5 (flange), B14 (face)
Efficiency : IE2 standard (IE3 optional)
Protection Class : IP54 (IP55 optional)
Insulation Class : Class F (155°C)
Ambient Temp. : -15°C to +40°C
Technical Table
| Type 型号 | Rated Output 功率 | Current电流 (A) | Power factor 功率因素 (cosφ) | Eff 效率 (%) | Rated Speed 转速 (r/min) | 堵转电流 额定电流 Ist/In | 堵转转矩 额定转矩 Tst/Tn | 最大转矩 额定转矩 Tmax/Tn | |
| KW | Hp | ||||||||
| YC711-2 | 0.18 | 1/4 | 2.3 | 0.72 | 60 | 2800 | 12 | 3 | 1.8 |
| YC712-2 | 0.25 | 1/3 | 2.9 | 0.74 | 64 | 2800 | 15 | 3 | |
| YC801-2 | 0.37 | 1/2 | 3.77 | 0.77 | 65 | 2800 | 21 | 2.8 | |
| YC802-2 | 0.55 | 3/4 | 5.19 | 0.79 | 68 | 2800 | 29 | 2.8 | |
| YC90S-2 | 0.75 | 1 | 6.4 | 0.82 | 70 | 2800 | 37 | 2.5 | |
| YC90L1-2 | 1.1 | 1.5 | 8.47 | 0.82 | 72 | 2800 | 80 | 2.5 | |
| YC90L2-2 | 1.5 | 2 | 11.3 | 0.81 | 74 | 2800 | 80 | 2.5 | |
| YC100L1-2 | 1.5 | 2 | 11.3 | 0.81 | 74 | 2800 | 80 | 2.5 | |
| YC100L2-2 | 2.2 | 3 | 16.5 | 0.81 | 75 | 2800 | 120 | 2.2 | |
| YC112M-2 | 3 | 4 | 21.9 | 0.82 | 76 | 2800 | 150 | 2.2 | |
| YC132S-2 | 3.7 | 5 | 26.6 | 0.82 | 77 | 2800 | 175 | 2.2 | |
| YC711-4 | 0.12 | 1/6 | 1.88 | 0.58 | 50 | 1400 | 9 | 3 | |
| YC712-4 | 0.18 | 1/4 | 2.49 | 0.62 | 53 | 1400 | 12 | 2.8 | |
| YC801-4 | 0.25 | 1/3 | 3.11 | 0.63 | 58 | 1400 | 15 | 2.8 | |
| YC802-4 | 0.37 | 1/2 | 4.24 | 0.64 | 62 | 1400 | 21 | 2.5 | |
| YC90S-4 | 0.55 | 3/4 | 5.49 | 0.69 | 66 | 1400 | 29 | 2.5 | |
| YC90L1-4 | 0.75 | 1 | 6.87 | 0.73 | 68 | 1400 | 37 | 2.5 | |
| YC90L2-4 | 1.1 | 1.5 | 9.52 | 0.74 | 71 | 1400 | 80 | 2.5 | |
| YC100L1-4 | 1.1 | 1.5 | 9.52 | 0.74 | 71 | 1400 | 80 | 2.5 | |
| YC100L2-4 | 1.5 | 2 | 12.5 | 0.75 | 73 | 1400 | 80 | 2.5 | |
| YC112M-4 | 2.2 | 3 | 17.8 | 0.76 | 74 | 1400 | 120 | 2.2 | |
| YC132S-4 | 3 | 4 | 23.6 | 0.77 | 75 | 1400 | 150 | 2.2 | |
| YC132M-4 | 3.7 | 5 | 28 | 0.79 | 76 | 1400 | 175 | 2.2 | |
FAQ
1 Q: Is AXSON a factory or a trading company?
A; AXSON is a factory.
2 Q: How long is the warranty period?
A; The warranty period for the equipment is 12 months from the Bill of Lading (B/L) date, with a 6-month warranty for spare parts (excluding wear parts).
3 Q:What is the payment terms?
A; 30% deposit by TT, with the remaining 70% payable before shipment or against copy of Bill of Lading (B/L).
4 Q: Does AXSON offer on-site support?
A; Yes, AXSON can dispatch engineers to provide on-site services, with the client bearing all associated costs for accommodation, meals, and interpreter services.
5 Q: How long is your delivery time?
A; If items are in stock, shipment will be made within 7-10 days. For made-to-order production, the lead time is 30 days.
6 Q: Can you provide a turnkey solution for the complete crushing plant?
A; We offer end-to-end solutions from design to commissioning, with full technical support. We have successfully executed multiple similar mining projects in China and overseas markets
7 Q: How to select the proper equipment model?
A: Please confirm the following details:
1.>Type of ore to be processed? (e.g. gold ore/granite/limestone)
2.>Feed size of raw material? (in millimeters)
3.>Required finished product size? (in millimeters)
4.>Production capacity requirements? (in tons per hour)
8 Q: Do you provide customized components and optional configurations?
A: We offer full customization including engines, screens, painting, etc., along with extensive optional packages.
9 Q: Why Choose Us as Your Equipment Manufacturer?
A: We don’t just deliver high-quality, cost-effective products—we also provide:
1.Customized solutions tailored to your needs
2. Professional end-to-end service
3. A more patient, detail-oriented, and responsible team
4. 24/7 support to ensure smooth operations
